Product description
The AG-LCD-55-OUT is a 55″ high-brightness outdoor display engineered for reliable operation in demanding outdoor environments. Its weather-resistant design ensures stable performance under varying environmental conditions, while the high-luminance panel delivers excellent visibility even in direct sunlight. The advanced display technology maintains consistent image quality and color performance over time. It is an ideal solution for outdoor information systems, digital signage applications, and any installation requiring outstanding visibility and durability.
Key features and characteristics
- Stainless steel housing
- Vandal-proof design
- Weatherproof construction
- Remote monitoring / remote management option
- Simple system integration
- High brightness display
- Energy-efficient operation
- Long-lasting, modular system
Technical parameters
| Display size | 55” |
| Resolution | FullHD / optional 4K |
| Brightness | 900 – 2500 nit |
| Energy consumption | 500W – 580W |
| Panel technology | TFT LCD |
| Aspect ratio | 16:9 |
| Contrast ratio | 1200:1 |
| Viewing angle | 178˚/178˚ |
| Surface treatment | Haze 3% |
| Material | Stainless steel |
| External dimensions | |
| Operating temperature range | -20~50˚C |
| Operating humidity | 10%-85% |
| IP code | IP54 |
| Protective glass | 6 mm laminated UV protected, Anti Glare, vandal proof |
| Input | AC 110-240V, 50/60Hz |
| Maximum consumption | 580W |
| HDMI input | x1 |
| Options | RK3288 / RK3399 / RK3568 / RK3588 (selectable) |
| I/O ports | HDMI ×1, USB ×2, RJ45 ×1, WiFi ×1 |
| Weight | 138 Kg |
Product drawing
Product photos
